Motorcycle paints Harley Davidson – Factory colors in 1K solvent-based  basecoat

Harley Davidson® paint - original color match

in Premium « 1K solvent-based basecoat » formula, for complete finishes, touch-ups or decoration.

in 250 ml to 2L cans or in aerosol sprays
Our paint kits are supplied in pure version + thinner (100 parts paint + 70 parts thinner)
The 250 and 500 ml formats are already diluted

The clearcoat supplied in the aerosol spray kits can be supplied in 1K basecoat version, exclusively on request by email, after order. By default, we provide 2K finish in the kits.
In aerosol spray : it will be a 1K basecoat in replacement of the 2K aerosol spray finish.

► TUTORIAL HOW TO PAINT A MOTORCYCLE

Order a Harley Davidson Factory Paint®

Choose the packaging* (see yield (m²/L) below to determine your needs)
Add to cart and order
Note the paint code/colour name Harley Davisdon, in the box provided, and/or by email after validation of the order
Shipment of the colour within the day / delivery in 48 H
example of original Harley Davidson Candy colour

check out the non-exhaustive list of Harley codes at the bottom of the page

Important!
The preparation of the Harley shade by the colorist must be done according to a colour code / HD colour name.
Without this colour code, but only the Brand/Model/Year, we cannot make the colour.
To know the colour code / colour name of your motorcycle, the safest way is to consult your dealer. It is also possible to find information on specialized forums.

If in doubt about a code or a 3-coat system, write to colors@stardustcolors.com
If the code is incorrect, the technician will contact you. In case of impossibility to make the colour, the order will be immediately refunded

The covering power or yield*

The pure Litre* in 2 passes : 5m².
1 aerosol spray 400 ml = 0.5m² maximum
* The yield of one pure litre is the same as one pure litre + 70% thinner

Surface of standard Harley Davidson parts

1 tank, 2 mudguards, 2 covers = 1 m² min
+ large Harley front fairing = 1.5 m² min
+ cases = 2.5 m² min

Quick Application Guide for Harley Davidson paint:

For Harley Davidson colors, it is recommended or even mandatory to apply the paint over a uniform background color, respecting the indications provided by the manufacturer. It is possible to apply the paint directly over the old paint, but if the HD shade is transparent, the final appearance may not match the original shade. Check out our Stardust Fast Grey or Black primer. This primer is very thin, does not require sanding, and is covered directly with the paint.

1/ Preparation of the base, according to the professional standards of body painting

Except in the case of an application on plastic or raw metal, the paint is generally applied as an overlay on an old paint / varnish / or primer

To guarantee the adhesion of the paint, sand lightly but carefully with 800 grit sandpaper and water. Rinse and dry.
Degrease (fingerprints, silicone, glue or grease) with our degreaser, soak a wiping paper, and remove the degreaser completely and immediately, with a dry and clean wiping paper, without waiting for evaporation;
Just before painting, pick up the dust on the part with our sticky wiping pad, without pressing.
Paint

2/ The paint

The Harley Davidson paint is applied with a body spray gun (medium nozzle of 1.0 to 1.4 mm with a pressure of 2.5 to 3 bars)
Start with an adhesion coat and wait for 2 minutes
Then apply 2 coats with 5 minutes between each. For metallic/pearl motorcycle paints, it is recommended to apply a final finer coat, 50 cm from the part, after 2 minutes.
It is important to varnish quickly after the application of the 1K basecoat because after 30 minutes, the motorcycle paint and the clearcoat will no longer stick together. Find more information on varnishing below

> Download the data sheet in red on this page

Harley paint all color codes
Harley Davidson® is the most creative and original motorcycle manufacturer in the choice of colors to paint its bodies : we find complex colors, truly custom, where special pearls, flakes and candies are often included in the formulation.
StardustColors is the specialist for the realization of Harley Davidson colors : thanks to our colorimetry service dedicated exclusively to motorcycle paint, and our databases updated every month, we have 80% of Harley fomulations. Our colorist can make with accuracy most of the Harley Davidson paints. Some new colors are not yet listed and are not communicated by the manufacturer unfortunately.

Special shades :

Some Harley Davidson paints are specific and are obtained by « 3-coat system »: If it is about your color code then our colorist will contact you in order to propose you the additional coat of paint (undercoat of color or colored clearcoat)

Topcoating :

It is important to varnish before thirty minutes in order to preserve the adhesion between the coats
Apply 2 coats of clearcoat with a 5 to 10 minutes interval,
Be sure to paint at an ambient temperature of at least 20°C
We offer a range of standard clearcoats (830 UHS, anti scratch, Ceramic or WET SPEED) and other special clearcoats

Our tips for those who paint outside the cabin :
- Disassemble the motorcycle and lay the parts flat and sufficiently spaced
- Before painting, make sure there is sufficient air circulation to avoid paint fumes falling on the paint
- Paint in dry and windless weather, out of humidity (to keep the clearcoat shiny and dust-free)

What is a 1K basecoat ?
Our motorcycle colors are delivered in a solvent-based « 1K basecoat »* for varnishing.
1K basecoat* : means that the painting is done in 2 steps, with the paint, then the clearcoat. As opposed to the 2K paint which is a paint with hardener, brilliant and resistant.
Therefore, each paint must be varnished in order to obtain the shine but also the resistance (gasoline, sun, water, projections..)

Other technical specifications :

Viscosity : 110-125 sec Ford N°4
Dry extract : 30-35 %
VOC g/L : <860 (diluted)
Product family : Polyester

Do you know Candy paint ?

Check out the true candy systems, ultra translucent and deep for Harley Davidson candy shades Harley-min.jpg

This product is offered for sale in accordance with the 2004/42/EC directive and the policy of reducing the use of solvents. The PDF is available at the top of this page. Exclusive use in professional booths

Colour Code motocycle Motorcycle colour name

MOTO DH HARLEY DAVIDSON-VIVID BLACK

MOTO ZQ HARLEY DAVIDSON-LUXURY RICH RED MET.

MOTO 107 HARLEY DAVIDSON-YELLOW MET

MOTO 645 HARLEY DAVIDSON-AMBER WHISKEY EFFECT.

MOTO 647/16 HARLEY DAVIDSON-MYSTERIOUS RED SUNGLO MET.

MOTO 652 HARLEY DAVIDSON-MOROCCO GOLD MET.

MOTO 905 HARLEY DAVIDSON-WHITE GOLD PEARL MET.

MOTO 905/06 HARLEY DAVIDSON-BLACK DENIM

MOTO 931 HARLEY DAVIDSON-ORANGE MANDARINO

MOTO BPS HARLEY DAVIDSON-CHERRY BLACK MET.

MOTO BXT HARLEY DAVIDSON-DEEP COBALT PRL.

MOTO BYM HARLEY DAVIDSON-BLACK DENIM

MOTO CGR HARLEY DAVIDSON-PEWTER PRL.

MOTO CGS HARLEY DAVIDSON-WHITE GOLD PEARL MET.

MOTO DCE HARLEY DAVISON-MERLOT SUNGLO PRL

MOTO DGX HARLEY DAVIDSON-SEDONA ORANGE MET.

MOTO DJO HARLEY DAVIDSON-BIG BLUE PRL.

MOTO DTC HARLEY DAVIDSON-MOROCCO GOLD MET.

MOTO DWF HARLEY DAVIDSON-DEEP JADE PEARL

MOTO DZT HARLEY DAVIDSON-VELOCITY RED SUNGLO MET.

MOTO DZW HARLEY DAVIDSON-OLIVE GOLD PRL.

MOTO EBC HARLEY DAVIDSON-ATOMIC RED MET.

MOTO HAD HARLEY DAVIDSON-WHITE GOLD PEARL MET.

MOTO 906 HARLEY DAVIDSON-CHERRY BLACK MET.

MOTO 6140 HARLEY DAVIDSON-AVORIO

MOTO 8100 HARLEY DAVIDSON-VERDE OLIVA

MOTO 8117 HARLEY DAVIDSON-VERDE BOSCO

MOTO 8205 HARLEY DAVIDSON-VERDE FOGLIA

MOTO 8206 HARLEY DAVIDSON-ROSSO ARANCIO

MOTO 8209 HARLEY DAVIDSON-ROSSO INCENDIO

MOTO 8213 HARLEY DAVIDSON-VERDE GIALLO

MOTO 8214 HARLEY DAVIDSON-AVORIO

MOTO 8217 HARLEY DAVIDSON-GIALLO OSSIDO

MOTO 8218 HARLEY DAVIDSON-AMARANTO

MOTO 8219 HARLEY DAVIDSON-VERDE PINO

MOTO 8221 HARLEY DAVIDSON-VERDE CONIFERA

MOTO 8224 HARLEY DAVIDSON-BIANCO INDIA

MOTO 8226 HARLEY DAVIDSON-ROSSO

MOTO 8228 HARLEY DAVIDSON-BLEU ORIENTE

MOTO 8229 HARLEY DAVIDSON-VERDE MUSCHIO

MOTO A888 HARLEY DAVIDSON-DK. RED MET

MOTO A889 HARLEY DAVIDSON-CANDY BROWN M

MOTO A890 HARLEY DAVIDSON-VIOLET MET.

MOTO A891 HARLEY DAVIDSON-VERDE MET.

MOTO A892 HARLEY DAVIDSON-BLUE MET.

MOTO A893 HARLEY DAVIDSON-BLU MET.

MOTO H998 HARLEY DAVIDSON-BLU PRL. MET.

MOTO I097 HARLEY DAVIDSON-MYRANG ORANGE MET.

MOTO I382 HARLEY DAVIDSON-BLU MET.

MOTO I383 HARLEY DAVIDSON-SILVER MET.

MOTO I385 HARLEY DAVIDSON-TURQUOISE

MOTO I393 HARLEY DAVIDSON-GRIGIO MET.

MOTO I507 HARLEY DAVIDSON-GRIGIO MET

MOTO I512 HARLEY DAVIDSON-GIALLO

MOTO I523 HARLEY DAVIDSON-GREY MET.

MOTO I709 HARLEY DAVIDSON-BLU MET.

MOTO I859 HARLEY DAVIDSON-ROSSO PRL.

MOTO V553 HARLEY DAVIDSON-BLU M (ULTRA CLASSIC MOTO PAG.

MOTO V584 HARLEY DAVIDSON-BLU VIOLA MET.

MOTO V585 HARLEY DAVIDSON-SILVER MET.

MOTO V608 HARLEY DAVIDSON-ARANCIO MET.

MOTO 90323/2 HARLEY DAVIDSON-NERO

MOTO HAR59 HARLEY DAVIDSON-TITANIO MET.
